3B6 SLIM User Manual

WARNING CODES
16
3B6 Operator Manual
WARNING 5
Rope overload
Exceeded single line pull of wire rope Increase reeving
Reduce weight
WARNING 6
Exceeded load
program change
Suspended load when changing
program
Lower load to ground to change
program
WARNING 7
Rigging & Travel
Rigging & Travel mode selected N/A
WARNING 8
Pre-warning
rotation
Rotation approaching limit range Increase Boom angle above 10
degrees
WARNING 9
Rotation limit stop
Exceeded rotation limits Increase Boom angle above 10
degrees
Rotate opposite direction
WARNING 10
5 vdc supply
rotation pot fault
5vdc supply is low to rotation pot Check wiring
Check harness to pot
Replace pot
WARNING 11
Virtual wall Angle
preset limit
Preset for virtual wall exceeded Increase boom angle
Reset ISAAC angle setting, page
14
WARNING 12
Virtual wall radius
exceeded
Preset for Virtual wall exceeded Decrease radius
Reset ISAAC radius setting, page
14
WARNING 13
Virtual wall
Height exceeded
Preset for Virtual wall exceeded Decrease height
Reset ISAAC height setting, page
14
WARNING 15
Virtual Wall
Rotation min
exceeded
WARNING 16
Virtual Wall
Rotation min
exceeded
Preset for Virtual wall exceeded
Preset for Virtual wall exceeded
Increase Rotation min (swing left)
Reset ISAAC ROT MIN setting,
see page 14 operator manual
Decrease Rotation Max (swing
right)
Reset ISAAC ROT MAX setting.
See page 14 operator manual
