The system is equipped with a preset range limiting feature, which will stop the crane
rotation to avoid contact with the outriggers. The lowest angle is 10 degrees, which will
stop the rotation in the contact direction, but allow the machine to swing back in the
opposite direction unless the angle is increased to enable the rotation to continue in that
direction. This feature is bypassed in Rigging and Travel mode only. The lowest angle
over the front is 10 degrees.
Warning 8 will flash on the display when the pre-warning alarm is enabled 2-3 degrees
prior to the shut-off point of rotation. Then Warning 9 will flash on the display when the
rotation is stopped. This mean the rotation feature is enable and stops the crane rotation
in the contact direction, but allows the crane to rotate back in the non- contact direction.
Warning 9
1.1 10.2
34.1 6 1 68
