System Components
6
3B6 Operator Manual
A2B Switch ACMCP Cable Reel
Pressure Sensors
Piston side located on top of the cylinder
Rod side located inside turret area
SLIM Display
Mounted on
outrigger swing
arm
A2B Switch CWT
Slew potentiometer
Located inside center
area of turret
Cable Sheave Guide
Main wire harness
Located inside turret area
Proximity switch
Located on swing
drive cover
