3B6 SLIM User Manual

Alarm/Fault codes
17
3B6 Operator Manual
MESSAGE CAUSE SOLUTION
ALARM 1
Memory Data
Fault
Internal memory fault Cycle system power, if continued
Contact Service
ALARM 2
Angle sensor 1
reading lower than
minimum
 Potentiometer inside Reel is faulty.
 Possible lack of continuity in wires
carrying the signals
 Fault in Display unit connector
 Angle out of adjustment
 Check Wiring from cable reel to
Display Unit
 Check 12vdc supply to angle
pot in cable reel
 Replace pot if damaged
 Check CAN BUS lines
 Call service
ALARM 3
Angle sensor 1
reading higher
than maximum
 Potentiometer inside reel is faulty.
 Lack of continuity in wiring
 Fault in display unit connector
 Angle out of adjustment
 Check Wiring from cable reel to
display unit
 Check 12vdc supply to angle
sensor
 Replace pot if damaged
 Check CAN BUS lines
 Call Service
ALARM 4
Length Sensor 1
reading lower than
minimum
 Potentiometer inside reel is faulty.
 Lack of continuity in wiring
 Fault in display unit connector
 Length out of adjustment
 Check Wiring from cable reel to
display unit
 Check 5 vdc supply to length
sensor
 Replace pot if damaged
 Adjust length pot values fully
retracted 0.250vdc
 Check CAN BUS lines
 Call Service
ALARM 5
Length Sensor 1
reading higher
than maximum
Potentiometer inside reel is faulty.
 Lack of continuity in wiring
 Fault in display unit connector
 Length out of adjustment
 Check Wiring from cable reel to
display unit
 Check 5 vdc supply to length
sensor
 Replace pot if damaged
 Adjust length pot values fully
retracted 0.250 vdc
 Check CAN BUS lines
 Call Service
