3B6 SLIM User Manual

MESSAGE CAUSE SOLUTION
ALARM 8
Piston pressure
sensor output
lower than
minimum
 Piston Pressure sensor faulty.
 Lack of continuity in wiring
 Moisture in connector.
 Sensor broken or disconnected
 Check for15vdc supply
 Check for output 0.5 vdc min
 Check for moisture or fluid.
 Check connector and wiring
• Replace Transducer if faulty
ALARM 9
Piston pressure
sensor output
higher than
maximum
 Piston Pressure sensor faulty.
 Lack of continuity in wiring
 Moisture in connector.
 Sensor broken or disconnected
 Check for15vdc supply
 Check for output 0.5 vdc min
 Check for moisture or fluid.
 Check connector and wiring
• Replace Transducer if faulty
ALARM 10
Rod pressure
sensor output
lower than
minimum
 Rod Pressure sensor faulty.
 Lack of continuity in wiring
 Moisture in connector.
 Sensor broken or disconnected
 Check for15vdc supply
 Check for output 0.5 vdc min
 Check for moisture or fluid.
 Check connector and wiring
• Replace Transducer if faulty
ALARM 11
Rod pressure
sensor output
higher than
maximum
 Rod Pressure sensor faulty.
 Lack of continuity in wiring
 Moisture in connector.
 Sensor broken or disconnected
 Check for15vdc supply
 Check for output 5.5 vdc max
 Check for moisture or fluid.
 Check connector and wiring
• Replace Transducer if faulty
ALARM 16
Shutoff output
fault.
 Lack of continuity in wiring
 Fault internal SLIM
 Shutoff solenoid
 Check for12vdc supply
 Check connector and wiring
ALARM 22
Internal WDO
fault
 Faulty display  Check wiring of display
and harness
ALARM 41
CRC Error
EPROM SW
Internal fault SLIM display Cycle power on SLIM display
Call Service
ALARM 42
CRC Error in
program
Internal fault SLIM display Cycle power on SLIM display
Call Service
ALARM 43
CRC Error in
Load chart
ALARM 50
Cable reel
CANBUS
Internal fault SLIM display
Faulty wiring from display to cable
reel
Cycle power on SLIM display
Call Service
Check wiring and CAN line for
120 ohm resistor.
3B6 Operator Manual
Alarm/Fault codes
18
