Press and release the WRENCH button and scroll to
the SENSOR line and press and release the ENTER
pushbutton to enter the diagnostics menu.
33
Top Master User Manual
Diagnostics
MAIN MENU 00
Access code
Sensors
ADC
560 1 1
341 1 1
0 1 2 3 4 5 6 7
KEY.1: . . . . . . .
KEY.2: . . . . . . .
INPUT: . . . . . . . .
OUT..: . . . . . . . .
LED..: . . . .
When the display changes to a 1 under the 0-7 area it indicates a high or signal for that
function. Means it is working properly when selected or weighing.
ADC Top Value = Pressure Sensor ADC Bottom Value= ASA Sensor
KEY.1 1=Wrench 2=Product 3=Client 4=SEL 5=Menu 6=Home 7= Print
KEY.2 1=Tare 2=Utility 3= UP 4=Right 5=Down 6=Left 7= Enter
INPUT 0=N/A 1=N/A 2= Total Zero 3=Partial Zero 4=Print 5=N/A 6=N/A 7=N/A
OUT.. 0= Enter 1=N/A 2=N/A 3= ASA input 4=N/A 5=N/A 6=N/A 7=ASA input
LED.. 0= Red 1= Green 2=Green 3=Green
