Top Master User Manual
Max Values
Each value shown on the display has a limit.
Loading truck with a fork lift / wheel loader we assume that after each truck (usually no
more than 40 metric tons) the total is zeroed.
If you use the system in other environments please read the table below that may contain
relevant system limits for your application.
If a value reach it’s limit the correspondent number will flash.
Please note that the “.” shown into the numbers below is the decimal separator sign.
Value
U.M. selected
Total load Partial
load
Bucket
n°
Target Load Display Totals
max value x
each material
shown
Min Max
Kg 9999990 99999 99 100 300000 99999999
ton 9999.99 300.00 99 0.1 300.0 99999.99
Lbs 4188740 99999 99 100 200000
4188740
iTon 3936.80 300.00 99 0.1 300.0
3936.80
sTon 4188.74 300.00 99 0.1 300.0
4188.74
