C TECHNICAL SPECIFICATIONS
Switch 4200G 12-Port
Physical Dimensions Height: 44 mm (1.7 in.) x Width: 440 mm (17.3 in.) x Depth: 274 mm (10.8 in.)
Weight: 4.4kg (9.72 Ibs)
Environmental Requirements
Operating Temperature 0 ° to 40 °C (32 ° to 104 °F)
Storage Temperature –10 ° to +70 °C (14 ° to 158 °F)
Operating Humidity 95% non-condensing
Standards
EN60068 to 3Com schedule (Package testing: paras 2.1, 2.2, 2.30, and 2.32.
Operational testing: paras 2.1, 2.2, 2.30 and 2.13).
Safety
Agency Certifications UL 60950-1, EN 60950-1, CSA 22.2 No. 60950-1, IEC 60950-1.
EMC
Emissions CISPRR 22 Class A, EN55022 Class A, FCC Part 15 Subpart B Class A,
ICES-003 Class A, EN61000-3-2, EN61000-3-3
Immunity EN 55024
Heat Dissipation 80 watts maximum (275 BTU/hour maximum)
Power Supply
AC
Line Frequency 50/60Hz
Input Voltage 100–240 VAC
Current Rating 1.5A (amps) maximum
