Viewing Statistics 39
Figure 18 Trunking Summary Screen
Viewing Statistics
The Statistics page shows a summary of traffic statistics
for all ports, as shown in
Figure 19.
Figure 19 Statistics Page
Figures that appear onscreen indicate the number of
packets transmitted (Tx) and received (Rx).
■ To reset all packet counts to zero, click Clear
Counters.
■ To view detailed statistics for each port, click the port
number. The statistics page for the port appears, as
shown in
Figure 20.
Figure 20 Port Statistics Page
Figures on the Statistics page for individual ports are not
updated in real time. To view the latest statistics for the
port, click Refresh.
Monitoring Traffic
The Switch allows you to monitor traffic going in and
out of a particular port. For traffic monitoring to work,
