Switch Rear View Detail 17
Console Port The console port allows you to connect a terminal and perform remote or
local out-of-band management. The console port uses standard null
modem cable and is set to auto-baud, 8 data bits, no parity and 1 stop
bit.
Matrix Port The Matrix Port allows you to:
Stack the Switch 3300 SM, TM or XM with another unit in the Switch
1100/3300 family using a single Matrix Cable
Stack the Switch 3300 MM with up to three other units in the Switch
1100/3300 family, using up to three Matrix Cables
For more information about the role of the Matrix Port, see Stacking
Units on page 29.
1697ua.bk Page 17 Monday, December 3, 2001 11:31 AM
