C
ONTENTS
A
BOUT
T
HIS
G
UIDE
Conventions 8
Related Documentation 9
Documentation Comments 10
Product Registration 10
1
I
NTRODUCING THE
S
WITCH
3300 XM, SM, TM, MM
About the Switch 12
Summary of Features 12
Switch — Front View Detail 13
10BASE-T/
100BASE-TX Ports 14
1000BASE-SX Port (SM only) 14
1000BASE-T Port (TM only) 14
LEDs 14
Switch — Rear View Detail 16
Unit Information Label 16
Power Socket 16
Redundant Power System Socket 16
Console Port 17
Matrix Port 17
Network Configuration Examples 18
Switch as a Segmentation Switch 18
Switch as a Collapsed Backbone Switch 19
Switch as a Desktop Switch 20
Configuration Rules for Fast Ethernet 21
Configuration Rules with Full Duplex 22
Configuration Rules for Gigabit Ethernet (SM and TM) 23
Configuration Rules for the 3300 SM and TM 23
