RJ45 Pin Assignments 45
Ports configured as MDIX
1 RxData + Receive Data
2 RxData – Receive Data
3 TxData + Transmit data
4 Not assigned
5 Not assigned
6 TxData – Transmit data
7 Not assigned
8 Not assigned
Ta bl e 7 Pin assignments
Pin Number Signal Function
