6
Important Safeguards (Continued)
Figure 1-4 Emergency Stop Switch
The 700rks is equipped with a latching emergency
stop switch shown in Figure 1-4. Pressing this
switch stops the machine upper and lower box drive
belts. To unlatch the switch after it has been
pressed, turn the switch knob clockwise.
IMPORTANT Read"Warnings" on page 18 before set-up, operation, maintenance or adjustments of
case sealer.
This safety alert symbol identifies important safety messages in this manual. Read and
understand them before installing or operating this equipment.
Figure 1-5 Air On/Off Valve
Pneumatic controls the air on/off valve has
provisions for lock out/tag out according to plant
regulations. See Figure 1-5.
