5.6 Mixer Shaft
Changing mixer shaft
1. Remove case base - see section 5.3
2. Remove both side covers - see section 5.4
3. Remove case bottom section - see section 5.5
4. Remove helical compression spring at back
5. Remove shaft securing of mixer shaft
6. Hold pinion
NOTE
There is a sliding seal ring between the pinion and helical compression spring
7. Pull mixer shaft towards front of unit to remove from case
8. Fit new mixer shaft in reverse order
9. Assembling housing - see section 5.20
10. Functional test - see section 6
5.7 Case Top Section
Changing case top section
1. Remove plunger discs - see section 5.2
2. Remove case base - see section 5.3
3. Remove both side covers - see section 5.4
4. Remove case bottom section - see section 5.5
5. Remove mixer shaft - see section 5.6
6. Push traverse right back using twist grip
7. Remove case top section
8. Fit new case top section in reverse order
9. Assembling housing - see section 5.20
10. Functional test - see section 6
