5.10 Clutch
Changing clutch
1. Remove plunger discs - see section 5.2
2. Remove case base - see section 5.3
3. Remove both side covers - see section 5.4
4. Remove case bottom section - see section 5.5
5. Remove mixer shaft - see section 5.6
6. Remove case top section - see section 5.7
7. Remove recessed-head screw of bearing plate
8. Lift off bearing plate using two screwdrivers
9. Lift off spur wheel and support ring
10. Release connection wires from terminal strip of PC board
11. Remove recessed-head screws of spool
12. Lift off spool
CAUTION
Pay attention to the slide bearing between the spur wheel
and drive shaft
13. Install new clutch in reverse order
14. Assembling housing - see section 5.20
15. Functional test - see section 6
5.11 Side Left
Changing side left
1. Remove plunger discs - see section 5.2
2. Remove case base - see section 5.3
3. Remove both side covers - see section 5.4
4. Remove case bottom section - see section 5.5
5. Remove mixer shaft - see section 5.6
6. Remove case top section - see section 5.7
7. Remove clutch - see section 5.10
8. Remove recessed-head screw connecting endpiece
9. Remove connection to bearing plate for mixer motor
10. Remove Allen screws connecting bottom plate on left-hand side
11. Remove left side complete using rubber hammer
12. Remove geared motor
13. Lift off chain and deflection roller
14. Install new side in reverse order
15. Check cut-off point - see section 5.19
16. Assembling housing - see section 5.20
17. Functional test - see section 6
