Pentamix
TM
2
7
General Description
4.2 Troubleshooting
CAUTION
Before starting up the PENTAMIX 2 for the first time, check
that the operating voltage and frequency indicated on the
rating plate correspond to the supply voltage and frequency
available.
m Visual check for defects
Before locating faults check the PENTAMIX 2 for mechanical damage.
Connect the PENTAMIX 2 to the power supply using the power cable and make a
functional check.
m Locate faults according to the following fault location diagram
CAUTION
When measurements are taken with the PENTAMIX 2
open, the power switch, feed motor, mixer motor, PC board
and power transformer are subject to hazardous voltages.
