Circuit Diagram / Drawings / Spare Parts List
7.3 Spare Parts list
Item Part Number Description .............................. pcs/Package
-- 77600 Wal Mounting Kit Pentamix ............................ 1
18 77780 Plunger Discs ............................................... 1
22,23 70201112722 Twist Grip Pentamix Mountage Kit ................. 1
-- 78990240208 Fuse 220/240 V/2 AMP (10pcs) ..................... 10
38 78990241222 Rubber Foot (RD) 12,7x3,5 ........................... 10
-- 78990241404 Microswitch Penta 2 ...................................... 1
40 78990241420 Power Cord 3POL USA/25H WS................... 1
-- 78990241438 Parallel Key A4x4x22 ..................................... 1
43-48 78990241503 Traverse comolete (Mounted) ........................ 1
2,4,5 78990241537 Bearing Plate Mounted Penta 2 ..................... 1
39 78990241545 Bottom Plate Penta 2 .................................... 1
33 78990241578 Mixer Shaft complete Penta 2 ........................ 1
51 78990241594 Case Bottom Section Penta 2 ....................... 1
9 78990241602 Left Hand Side Cover Penta 2 ....................... 1
25 78990241610 Right Hand Side Cover Penta 2 ..................... 1
19 78990241628 Case Lid Penta 2 ........................................... 1
36 78990241636 Base Penta 2 ................................................ 1
7 78990241644 Case Lid of left Side Cover Penta 2 ............... 1
37 78990241677 Base Cover Penta 2 ...................................... 1
11 78990241685 Large Traverse Cover 36mm Penta 2 ............ 1
15 78990241693 Small Traverse Cover 20mm Penta 2............ 1
20 78990241826 Drive Shaft Penta 2 ....................................... 1
49 78990241834 Deflection Roller Penta IMP/2 ........................ 1
50 78990241842 Chain complete Penta 2 ................................ 1
34 78990241859 Endpiece Penta 2 .......................................... 1
29 78990241867 Helicoil Compression Spring P2 .................... 1
31 78990241875 Pinion Penta 2 ............................................... 1
30 78990241883 Sliding Seal Rings Penta 2 ............................ 10
52 78990241891 Case Power Button Penta 2 .......................... 1
42,44 78990241909 Case Top complete Penta 2 .......................... 1
3 78990241941 Feed Motor Penta 2 ....................................... 1
26-41 78990241958 Mixer Motor Penta 2 ....................................... 1
35 78990242402 PC Board 120V Penta 2 ................................ 1
1,6,10 78990242410 Left Side complete Penta 2 ........................... 1
10,21,24 78990242428 RIight Side complete Penta 2 ........................ 1
40 78990242766 Power Cable - GB. ........................................ 1
40 78990243004 Power Cable AUS.......................................... 1
53 78990243111 Power Switch Complete ................................ 1
35 78990243228 PC Board 230 V Penta 2 .............................. 1
40 78990243244 Power Cable CH ........................................... 1
40 78990243251 Power Cable EU............................................ 1
3 78990243921 Feed Motor 230 V Penta 2 ............................ 1
8 78990243939 Clutch Penta 2.............................................. 1
26-41 78990243947 Mixer Motor 230 V Penta 2 ............................. 1
