Page 44
This is an example of output from the read program and the RMAP plug-in. Some extra newlines have been
added for better readability in this manual.
9.4. Waveform Handling
Blocks of waveform data are embedded in the recorded file at the points where events were detected by the
MSR.
When the read program is run, a pop-up window will show each waveform as it is encountered in the recorded
file. This window shows the time-tag of the event that triggered the waveform capture, an indication of the type
of event, and the time scale of the recording. The time scale may be adjusted using a pull-down menu. The
waveform may by saved to a file (with the default extension .swf - SpaceWire WaveForm, not ShockWave
Flash®) using the button provided.
Saved waveforms may be viewed using the supplied waveform.jar program:
java -jar waveform.jar <waveform-file-name>
After you have viewed or saved the waveform, a prompt generated by the read program reminds you to close
the waveform pop-up window in order to see the next waveform in the recorded file.
If your MSR unit supports multiple SpaceWire ports, event waveforms for all of the ports will be stored in the
recorded file in an interleaved fashion. After viewing a waveform, it will be necessary to follow the prompt to
close the pop-up window for the correct port in order to view the next event waveform.
// Added Rx protocol "RMAP" (v13:20111125) from ProtocolRx_RMAP
//-4Links.READ (v16:20111125/v33:20110920) run by test-user on 2012-05-18 14:29:37 Z (GB)
//- msr-test-rmap.msr /p RMAP
//- PC time at start of recording was 2012-05-17 17:50:53 (daylight saving time)
//- NOTE: This may not be the time of the first shown activity.
Ss ms us ns Flow Activity
18 404.197 654 640 0s 5-->6 RMAP Read command: To 21, Reply to FE, Transaction ID 0001,
Key 00: 000028 bytes from 00:00000000... (Header CRC OK)
18 404.197 673 973 3s 5<--6 RMAP Read reply: To FE, From FE, Transaction ID 0001,
Status = OK: F5 F5 F5 F5 F5 F5 F5 F5 F5 F5 F5 F5 F5 F5 F5 F5... >
RMAP_Read_reply_FE_0001.bin (Header CRC OK) (Data CRC OK)
18 404.202 991 333 3s 5-->6 RMAP Write command: To 21, Reply to FE, Transaction ID 0002,
Key 00,
0007ED bytes: ED ED ED ED ED ED ED ED ED ED ED ED ED ED ED ED... >
RMAP_Write_command_21_0002.bin to 00:00000000... Acknowledge
(Header CRC OK) (Data CRC OK)
18 404.205 195 801 3s 5<--6 RMAP Write reply: To FE, From FE, Transaction ID 0002,
Status = OK (Header CRC OK)
