Interfaces
Antenna Interface
2 x TNC, 50 ohm, female connectors
Software selectable single or dual antenna port operation.
Ethernet Interface
2, 3 or 4 ports 10/100 base-T Ethernet layer 2 switch using RJ-45
Used for Ethernet user traffic and product management.
RS-232 Interface
2, 1 or 0 RS-232 asynchronous ports using RJ-45 connector
Used for RS-232 asynchronous user traffic only.
USB Interfaces
1 x Management Port using USB micro type B connector
Used for product configuration with the Command Line Interface (CLI).
1 x Host Port using USB standard type A connector
Used for software upgrade and diagnostic reporting.
Alarm Interface
1x Alarm Port using RJ-45 connector
Used for monitoring and control of protection switches.
AUX Interface
1x Port using a QMA female connector
Reserved for future use.
