Aprisa SR+ Product Description
Power Specifications
Power Supply
Aprisa SR+ Radio
Nominal voltage
+13.8 VDC (negative earth)
Input voltage range
+10 to +30 VDC
Maximum power input
30 W
Connector
Molex 2 pin male screw fitting
39526-4002
Aprisa SR+ Protected Station
Nominal voltage
+13.8 VDC (negative earth)
Input voltage range
+10 to +30 VDC
Maximum power input
35 W
Connector
2x Molex 2 pin male screw fitting
39526-4002
Aprisa SR+ Data Driven Protected Station
Nominal voltage
+13.8 VDC (negative earth)
Input voltage range
+10 to +30 VDC
Maximum power input
35 W
Connector
2x Molex 2 pin male screw fitting
39526-4002
Power Consumption
Aprisa SR+ Radio
Mode
Power Consumption
(10 W radio with 4-CPFSK modulation)
Transmit / Receive
< 35 W for 10 W transmit power
< 25.0 W for 1 W transmit power
Receive only
< 6 W full Ethernet traffic activity
< 4.5 W no Ethernet traffic activity
Aprisa SR+ Protected Station and Aprisa SR+ Data Driven Protected Station
Mode
Power Consumption
(10 W radios with 4-CPFSK modulation)
Transmit / Receive
< 42 W for 10 W transmit power
< 32.0 W for 1 W transmit power
Receive only
< 14.5 W full Ethernet traffic activity
< 11.5 W no Ethernet traffic activity
