4RF Aprisa SR+ - General Specifications; Environmental; Mechanical; Compliance

Specifications | 29
Aprisa SR+ Product Description
General Specifications
Environmental
Operating temperature range
-40 to +70˚ C
Storage temperature range
-40 to +80˚ C
Operating humidity
Maximum 95% non-condensing
Acoustic noise emission
No audible noise emission
Mechanical
Aprisa SR+ Radio
Dimensions
Width 210 mm
Depth 130 mm (146 mm with TNC
connectors)
Height 41.5 mm
Weight
1.25 kg
Colour
Matt black
Mounting
Wall (2 x M5 screws)
Rack shelf (2 x M4 screws)
DIN rail bracket
Aprisa SR+ Protected Station
Dimensions
Width 432.6 mm
Depth 372 mm (388 mm with TNC
connectors)
Height 2U plus external duplexer (if used)
Weight
12 kg (includes the 2 radios)
Colour
Matt black
Mounting
Rack mount (2 x M6 screws)
Compliance
Radio
EN 300 113-2
EMI / EMC
EN 301 489 Parts 1 & 5
Safety
EN 60950-1:2006
Environmental
ETS 300 019 Class 3.4
