A.O. Smith 101 Series Service Handbook

Servicing should only be performed by a Qualified Service Agent
11
OPERATION & SERVICE
Ohms Law
A law that explains the relationship between voltage, current and resistance. The law states
that the electric current flowing through a conductor is equal to the voltage divided by the
resistance. The following equations further explain ohms law.
V=Volts (electrical pressure)
A=Amps (electrical flow/current)
O=Ohms (resistance to electrical flow/current)
W=Watts (rate or amount of electricity used)
Ohms Law applied to single phase power - each loop of a six wire element:
Ohms Law applied to three phase power - each wiring lead to a three wire element:
Service Note: See Heating Element Ratings on page 23 to determine the voltage and KW
rating of a heating element.
V ÷ A = O W ÷ V = A V ÷ O = A V x A = W A x O = V W ÷ A = V
0.577 x W ÷ V = A V x A x 1.73 = W
