A.O. Smith BTX 100 Service Handbook

39






     
                


CCB ENCLOSURE WITH FRONT REMOVED
CCB CIRCUIT BOARD
120 VAC X 24 VAC
50 VA TRANSFORMER

CCB ENCLOSURE
FRONT COVER ON
FRONT
TOP OF WATER HEATER FRONT COVER REMOVED
CCB CIRCUIT BOARD MOLDED CLIPS
RAISED EDGES (3)
FOR WIRING
STRAIN RELIEF
COVER SCREWS (2)CCB ENCLOSURE TRANSFORMER COVER

