A.O. Smith T-H3-DV Service Manual

5 Page
240 (T-H3J), 340 (T-H3S) and 540 (T-H3) models Service Manial
Ver. 1.00
CONFIDENTIAL
Outdoor models
Side view
Front view
17-5/8" (448 mm)
6-1/4" (159 mm)
COLD 5/8" (17 mm)
120 VAC 3" (77 mm)
HOT 5-1/2" (140 mm)
HOT 4-3/4" (120 mm)
7-1/2" (189 mm)
Condensate drain port
GAS 5-1/8" (131 mm)
COLD 6-3/4" (172 mm)
7-7/8" (199 mm)
Drain port
7-1/2" (189 mm)
10-3/4" (272 mm)
22-1/2" (570 mm)
120 VAC
Condensate drain port
7-7/8" (199 mm)
Condensate drain port
11" (281 mm)
1/2" (13 mm)
120 VAC 3" (77 mm)
GAS (131 mm)
HOT (140 mm)
COLD 6-3/4" (172 mm)
Condensate drain port
COLD 5/8" (17 mm)
GAS 5-3/4" (147 mm)
HOT 4-3/4" (120 mm)
6-3/4" (170 mm)
1-1/2" (37 mm)
11-1/4" (285 mm)
120 VAC 6-1/4" (159 mm)
17-3/4" (450 mm)
7" (180 mm)
23-5/8" (600 mm)
24-7/8" (631 mm)
3-5/8" (92 mm)
4-1/2" (114 mm)
Drain port 6" (152 mm)
Bottom view
Top view
