A.O. Smith Upsilon User Manual

Installation and Service Manual Upsilon-Series
66
Upsilon 1 boiler, wall hung Upsilon 2 boilers, wall hung, max.200kW
Upsilon 1 boiler, free-standing Upsilon 2 boilers, free-standing, max. 200kW
NumberofUpsilon‐boilers(UB70,UB110,UB140
)
1 2 1 2
Necessaryarticles:
0310265 L‐shapeframeforbacktobackalignmen
t
2 2
031026
6
I‐shapeframeforlinealignment 1
0310267 Boilerframe 1 2
0310335 Lowvelocityheaderfor1or2boilers(max.200kW
)
1 1 1 1
0310286 Boilerconnectionsetforsingleboile
r
1 2 1 2
0310289 Buscommunicationcable 1 1
0310290 Commonflowsensor10kOhmT3/T1
0
1 1 1 1
Supplyofconnectionpipes,fittingsandbracketsbythirdparty
.
wallhung freestanding
3/8”
1/2”
34
26
56
660 440 529 352
1 1/2” (4x)
48
1/2”
2” (2x)
