5. PTZ
a. Pan Limit (OFF), ON
b. Pan Left Limit (DF=000), +179 to -179
c. Pan Right Limit (DF=000), +179 to -179
d. Pan B-Zone Speed (DF=2), 0 to 23
e. Pan C-Zone Speed (DF=12), 0 to 23
f. Pan D-Zone Speed (DF=22), 0 to 23
g. Tilt Limit (OFF), ON
h. Up Limit (DF=000), 000 to 115
i. Down Limit (DF=000), 000 to 115
j. Tilt B-Zone Speed (DF=2), 0 to 23
k. Tilt C-Zone Speed (DF=12), 0 to 23
l. Tilt D-Zone Speed (DF=22), 0 to 23
m. Zoom B-Zone Speed (0) to 7
n. Zoom C-Zone Speed (DF=3), 0 to 7
o. Zoom D-Zone Speed 0 to (7)
p. Hi Zoom Speed (DF=6), 0 to 7
q. Lo Zoom Speed (DF=1), 0 to 7
r. Dead Zone (DF=10%), 0 to 20%
6. Picture
a. Effect (OFF), Negative and B&W
b. Aperture (MIN), 01 to 14, MAX
7. System
a. OSD (OFF), ON
b. IR Control (OFF), ON
c. Image Orientation (Normal), Vert Rev, Horz Rev and H/V Rev
d. Info Display (OFF), ON
e. Camera Select (Asystem), Pelco-D
f. Controller ID (1) to 8
