GX-A Series/GF-A Series Communication Manual 18 / 41
CSV format RS-232C connection： internal setting
USB connection： internal setting
□ Separates the data of A&D standard format and the unit by a comma (,).
□ Outputs the unit even when the data is overloaded.
□ When the decimal point is set to comma (,), semicolon (;) will be used as the separator.
□ When other data is added to the weighing value, all data will be displayed in one line.
The display sample will be as follows if the ID number, data number, date and time are added.
TAB format RS-232C connection： no function
USB connection： internal setting
□ This is a format, in which the separator of the CSV format is changed from comma to TAB.
S T , + 0 0 1 2 3 . 4 5 _ _ g CR LF ,
SAMPLE-0123-4,No,012,2017/07/01,12:34:56,ST,+00123.45, g
ID
number
Data number Date Time
Weighing
data
TAB S T + 0 0 1 2 3 . 4 5 _ _ g CR LF TAB
<TAB> is the ASCII:09h code
