APPENDIX A - BACnet
®
Points
17 BACnet
®
General Controller Technical Guide
BACnet
®
Properties for the BGC
PARAMETER OBJECT DESCRIPTION LIMITS
Analog Input
#1 Type
AV: 5 Analog Input #1 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#2 Type
AV: 6 Analog Input #2 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#3 Type
AV: 7 Analog Input #3 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#4 Type
AV: 8 Analog Input #4 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#5 Type
AV: 9 Analog Input #5 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#6 Type
AV: 10 Analog Input #6 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#7 Type
AV: 11 Analog Input #7 Type
Conguration
SeeEnumerated
values this page.
Analog Input
#8 Type
AV: 12 Analog Input #8 Type
Conguration
SeeEnumerated
values this page.
Maximum
Scaling #1
AV: 13 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #2
AV: 14 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #3
AV: 15 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #4
AV: 16 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #5
AV: 17 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #6
AV: 18 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #7
AV: 19 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Maximum
Scaling #8
AV: 20 Maximum Scaling for
UserScaled
Conguration
-3000 3000
Minimum
Scaling #1
AV: 21 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Minimum
Scaling #2
AV: 22 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Minimum
Scaling #3
AV: 23 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Minimum
Scaling #4
AV: 24 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
BACnet
®
Properties for the BGC
PARAMETER OBJECT DESCRIPTION LIMITS
Minimum
Scaling #5
AV: 25 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Minimum
Scaling #6
AV: 26 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Minimum
Scaling #7
AV: 27 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Minimum
Scaling #8
AV: 28 Minimum Scaling for
User-Scaled
Conguration
-3000 3000
Sensor # AV: 29 Analog Input #1
Communicating
Sensor #
1 8
Sensor # AV: 30 Analog Input #2
Communicating
Sensor #
1 8
Sensor # AV: 31 Analog Input #3
Communicating
Sensor #
1 8
Sensor # AV: 32 Analog Input #4
Communicating
Sensor #
1 8
Sensor # AV: 33 Analog Input #5
Communicating
Sensor #
1 8
Sensor # AV: 34 Analog Input #6
Communicating
Sensor #
1 8
Sensor # AV: 35 Analog Input #7
Communicating
Sensor #
1 8
Sensor # AV: 36 Analog Input #8
Communicating
Sensor #
1 8
BGC BACnet
®
Points
BGC BACnet
®
Property Identier
BACNETPropertyIdentier :
AnalogInputTypeCongurationBits ::=ENUMERATED{
NotUsed (0),
Thermistor Temp (Fahrenheit) (1),
Thermistor Temp (Celsius) (2),
4-20maUserScaled (3),
0-5vdcor0-10vdcUserScaled* (4),
Communicating Digital Space Sensor (5),
Communicating Carbon Dioxide Sensor (6),
Communicating Outdoor Temp Sensor (7),
Communicating Return Temp Sensor (8)
*Setjumperfor0-5VDCor0-10VDCoperation.
