START-UP TECHNICIAN: START-UP VERIFIED BY:
JOB NAME:
RL START-UP FORM • Page 2 of 2
SERIAL No:
MODEL No:
DATE:
AAON
®
MOTOR MAKE & AMPS
1
POWER EXHAUST / RETURN ASSEMBLY
2
MOTOR MAKE & AMPS
3 Ø 3 Ø
ALIGNMENT ❏ CHECK ROTATION ❏ NAMEPLATE AMPS ___________
INDICATE ECONOMIZER TYPE:
ECONOMIZER ASSEMBLY
OPERATION CHECK ❏
ECON. MOTOR TYPE:
ECON. CHANGEOVER TYPE & OPERATION:
GEARS CHECK:
CHECK ALL ECON. WIRING:
VERIFY INLET GAS PRESSURE: (refer to data plate) WC
GAS HEATING TEST
NATURAL GAS ❏ LP GAS ❏ STAGES OF HEAT ___________________
PURGE AIR FROM LINES ❏ VERIFY PILOT SPARK ❏
MANIFOLD PRESSURE: SINGLE STAGE WC
1st STAGE LOW FIRE WC
2nd STAGE HIGH FIRE WC
MANIFOLD LEAKAGE ❏
BURNER LIGHTS ❏ FLAME CORRECT ❏
MAIN LIMIT ❏ FAN ON / OFF ❏
AUX. LIMIT ❏ ROLLOUT SW. ❏
HEATER NUMBER & AMPS
ELECTRIC HEATING TEST
STAGES OF HEAT ___________________
LIMIT LOCKOUT ❏
AUX. LIMIT LOCKOUT ❏
DOOR INTERLOCK ❏
1
2
3
4
5
6
7
8
9
10
11
12
13
14
ADDITION NOTES • CONTROLS • OPTIONS
