Aastra 9417CW User Manual

5
Connecting an optional fax machine or modem
Attach the line cord to jack number 2 and
the other end to the modem or fax
machine. This line cord is not supplied
with the telephone.
To avoid potential electrical shock hazard to personnel or damage to
the telephone, use only the manufacturer-supplied equipment and
installation procedures. Specifically, use only 4 conductor modular
teledapt plug/cords with this product, and an AC transformer that is
CSA/UL or CSA-NRTL/C approved Class 2 level C, rated as follows:
For North American Markets mains nominal AC voltage 110-
117V, Input: 110/117VAC, 50/60Hz, 10W and Output: 16VAC 250mA.
For International Markets mains nominal AC voltage 220-240V,
Input: 220/240VAC, 50/60Hz, 10W and Output: 16VAC 250mA.
Substitution of non-approved equipment will void the Aastra Telecom
Inc., warranty. For more information about installation and safety con-
cerns, call 1-800-574-1611.
2
1
P0844339 04 E UG 9417CW Page 5 Thursday, April 20, 2000 11:09 AM

Aastra 9417CW Specifications

Power

power type	16 Vac transformer
voltage message waiting indicator	CLASS

Weight and Dimensions

weight	2.3 lbs
length	7.5”
width	7.5”
height	3.5”
