The second interval begins by pulling in the climber . It is finished when
the climber reaches its topmost position.
Because the s-max sella is always pulled slightly backward, it rolls automati
-
cally to the next step and reaches the initial position again - both main
wheels touch the next step .
If you active the single step mode, the climbing process ends here. To resu
-
me climbing, you need to press the UP/DOWN switch once again, direction
"UP".
At this point the climbing process repeats itself as described in point 7.
28
s-max sella · 160 kg
1
1
2
