you can increase or decrease the gain from -155 to + 100 Use arrows
to proceed.
DATE
- Date allows you to choose the position of the current date inser-
tion inside the video image. Use arrows to proceed.
TIME
- Time allows you to choose the position of the current time inser-
tion inside the video image. Use arrows to proceed.
CAM
- Cam allows you to choose the position of the current cam insertion
inside the video image. Use arrows to proceed.
FRAME
- Frame On/Off allows you to choose if you want or not a frame to
be inserted in the video image.
- Frame 1,2,3 or 4, allows you to memorize 4 different frames. The
4 frames can not be inserted at the same time.
- Frame Top Left allows you to choose the top-left position of the fra-
me. Use arrows to proceed.
- Frame Bottom Right allows you to
choose the bottom-right position of the frame. Use arrows to proceed.
- Frame move allows you to move the complete frame in the picture.
Use arrows to proceed.
- Edge Shadow allows you to choose between a white or black edge
around the frame or no edge. Use arrows to proceed.
51
THE CAMERA BODY
Vitc lines
• First line is the video timeco-
de line. Each time you switch
on the video assist, the video
timecode is set to 1:00'00'' 00
(the last number is the image
number). The time count is
continuous regardless of the
camera.
• Second line is the keycode
line. As the keycode should be
read from the film, this line
cannot be generated. Only
synchonization and checksum
bits are inserted.
• Third line is the audio time-
code line, i.e. all the timecode
information of the AatonCode
are inserted here.
