16 Chapter 3 Installation and wiring Manual Corrigo Ventilation, revision R
A number of different wiring alternatives are possible depending on the type of supply voltage to
the Corrigo and the relay type.
24 V AC supply and 24 V AC relays
24 V DC supply and 24 V DC relays
24 V AC supply and 24 V DC relays
G
G
0
10
11
12
L
N
24 V
AC
G
G
0
10
11
12
+
-
24 V DC
+ -
+ -
+ -
G
G0
10
11
12
L
N
24 VAC
24 V DC
+ -
+ -
+ -
+ -
24 V AC
24 V AC
