18 Chapter 3 Installation and wiring Manual Corrigo Ventilation, revision R

Description E tool
©
Display
Intake temperature Intake Temp Intaketemp
Extra temperature sensor 1
Extra Sensor Temp 1
Extrasensor
Extra temperature sensor 2 Extra Sensor Temp 2 Extrasensor 2
Extra temperature sensor 3
Extra Sensor Temp 3
Extrasensor 3
Extra temperature sensor 4 Extra Sensor Temp 4 Extrasensor 4
Extra temperature sensor 5 Extra Sensor Temp 5 Extrasensor 5
Extra pressure transmitter supply air
Extra SAF Pressure
Extra SAF Pressure
Extra pressure transmitter extract air Extra EAF Pressure Extra EAF Pressure
External flow pressure transmitter
External flow setpoint
Ext sp flow
Analogue filter guard 1 Filter Guard 1 Filter alarm 1
Analogue filter guard 2 Filter Guard 2 Filter alarm 2
Digital input signal

Description E tool
©
Display
Inactive input
Not active
Not active
Filter guard, supply air Filter Guard 1 Filter alarm 1
Filter guard, extract air
Filter Guard 2
Filter alarm 2
Run-indication/alarm circulation pump,
Heating
Heat Pump Indication P1-Heating
Run-indication/alarm circulation pump,
exchanger
Exchange Pump Indication P1-Exchanger
Run-indication/alarm circulation pump,
Cooling
Cooling Pump Indication P1-Cooling
Fire alarm
Fire Alarm
Fire alarm
Fire damper end-switch monitoring Fire Damper Indication Fire damper-ind
Extended operation, Normal
Extended Operation, Normal
Ext run 1/1
Extended operation, Reduced Extended Operation, Reduced Ext run 1/2
External switch External Switch External switch
External alarm
External Alarm
External alarm
Flow switch Flow Switch Flow guard
Rotation guard exchanger
Exchange Rotation
Rot.sent.exch
Run-indication/alarm supply air fan SAF Indication SAF-Ind
Run-indication/alarm extract air fan EAF Indication EAF-Ind
Deicing thermostat exchanger
Deicing
De-icing
Frost protection thermostat water heater Frost Protection Frostprotection
High temperature limit switch
Overheated Electric heater
Overheatprotection
Recirculation start Recirculation Recirculation
Change over Change over Change over
The universal inputs on Corrigo E28 can be individually configured as either analogue inputs, using
any of the analogue input signals above, or as digital inputs using any of the digital inputs above.
