Manual Corrigo Ventilation, revision R Chapter 11 Air control 63
Submenu “Compensation only when”
Compensation only
when:
1/1-speed: No
defrosting: No
Flow units can be measured in both m
3
/h (cubic meters per hour) and in CFM (cubic feet per
minute).
Flow control SAF (there are corresponding menus for EAF)
Flow control SAF
Actual: 1800 m3/h
Setp.: 2000 m3/h

Submenu "Setpoint"
Flow control SAF
Setp 1/1: 2000 m3/h
Setp 1/2: 1000 m3/h
Submenu "Outdoor compensation"
Outdoor comp. setp.
-20 °C = 0.0 m3/h
10 °C = 0.0 m3/h
Act. Comp: 0.0 m3/h
Submenu "Extra compensation curve"
Comp.sens.:Roomtemp1
15 °C = 0 m3/h
20 °C = 0 m3/h
25 °C = 0 m3/h
Submenu “Controller output compensation if cooling”
Controller output
comp if cooling
0 at HCOUT= 0%
100 at HCOUT= 0%
Submenu “Controller output compensation if heating”
Controller output
comp if heating
0 at HCOUT= 0%
100 at HCOUT= 0%
The compensation follows the current control quantity, in this case pressure.
Submenu “Controller output compensation”
Controller output
compensation
Not active
Submenu “Compensation only when”
Compensation only
when:
1/1-speed: No
defrosting: No
