64 Chapter 11 Air control Manual Corrigo Ventilation, revision R
Flow units can be measured in both m
3
/h (cubic meters per hour) and in CFM (cubic feet per
minute).
Manual frequency control SAF (there are corresponding menus for EAF)
Frequency control
manual SAF
Output: 75%
Submenu "Setpoint"
Frequency control
manual SAF
Output 1/1: 75%
Output 1/2: 50%
Submenu "Outdoor compensation"
Outdoor comp. outp.
-20 °C = 0 %
10 °C = 0 %
Act. Comp: 0 %
Submenu "Extra compensation curve"
Comp.sens.:Roomtemp1
15 °C = 0 %
20 °C = 0 %
25 °C = 0 %
Submenu “Controller output compensation if cooling”
Controller output
comp if cooling
0 at HCOUT= 0%
100 at HCOUT= 0%
Submenu “Controller output compensation if heating”
Controller output
comp if heating
0 at HCOUT= 0%
100 at HCOUT= 0%
The compensation follows the current control quantity, in this case %. The function
should not be used when fan setpoint is set to %, as the fans will then risk stopping in
some modes.
Submenu “Controller output compensation”
Controller output
compensation
Not active
Submenu “Compensation only when”
Compensation only
when:
1/1-speed: No
defrosting: No
Flow units can be measured in both m
3
/h (cubic meters per hour) and in CFM (cubic feet per
minute).
CO2
CO2
Actual:920ppm
Setp:850pm
