ABB 2600T EN Series User Manual

- 14 -
. . . INSTALLATION
Fig. 6b
Adapter angle (90°) entry connection (
7
/16in – 20 UNF drilling)
86 (3.39)
S
N
O
S
S
T
I
U
C
R
I
C
S
E
L
N
O
I
N
E
T
S
O
S
T
U
R
R
E
V
U
O
C
E
L
R
E
D
R
A
G
T
N
E'
M
E
F
N
E
B
E
L
C
I
Q
U
A
T
E
A
L
S
T
I
U
C
R
I
C
I
V
E
H
C
O
P
E
E
K
V
E
R
T
I
G
T
E
H
W
N
!
ø 65 (2.56)
18 (0.71)
100 (3.94)
49.5 (1.95)
ø 41.3
(1.63)
ø 39 (1.54)
135 (5.31)
31 (1.22)
127 (5.00)
17 (0.67)
17 (0.67)
36 (1.42)
16 (0.63)
42.5 (1.67)

ABB 2600T EN Series Specifications

General

Accuracy	±0.075% of span
Process Temperature	-40 to 85 °C (-40 to 185 °F)
Ambient Temperature	-40 to 85 °C (-40 to 185 °F)
Power Supply	10.5 to 45 V DC
Housing Material	Aluminum or Stainless Steel
Type	Pressure Transmitter
Output Signal	4-20 mA HART, PROFIBUS PA, FOUNDATION Fieldbus
Protection Rating	IP66, IP67
Measurement Type	Absolute, gauge, differential pressure
Stability	±0.1% of URL per year
Electrical Connection	M20x1.5, 1/2-14 NPT
Process Connection	1/2" NPT, 1/4" NPT
Certifications	ATEX, IECEx, CSA
Communication Protocol	HART, PROFIBUS PA, FOUNDATION Fieldbus
