Released User Manuals and Release Notes
A complete list of all User Manuals and Release Notes applicable to System 800xA
is provided in System 800xA Released User Manuals and Release Notes
(3BUA000263*).
System 800xA Released User Manuals and Release Notes (3BUA000263*) is
updated each time a document is updated or a new document is released. It is in pdf
format and is provided in the following ways:
• Included on the documentation media provided with the system and published
to ABB SolutionsBank when released as part of a major or minor release,
Service Pack, Feature Pack, or System Revision.
• Published to ABB SolutionsBank when a User Manual or Release Note is
updated in between any of the release cycles listed in the first bullet.
RLM 01 Redundancy Link Module for PROFIBUS DP. The
RLM 01 connects a non redundant PROFIBUS slave to
the line redundant PROFIBUS.
RS485 A communication interface standard from EIA
(Electronics Industries Association, USA), operating on
voltages between 0V and +5V. RS485 is more noise
resistant than RS232C, handles data transmission over
longer distances, and can drive more receivers
Segment A Segment is a section of a PROFIBUS DP fieldbus that
is terminated in its characteristic impedance. Segments
can be linked by Repeaters to form a longer PROFIBUS
DP fieldbus. Each Segment can include up to 32
devices.
tbit Time a bit needs to be transferred on PROFIBUS. This
time depends on the transmission rate.
tbit = 1/transmission rate.
A product bulletin is published each time System 800xA Released User Manuals
and Release Notes (3BUA000263*) is updated and published to ABB
SolutionsBank.
Term/Acronym Description
