Section 2 Transmission Media and Components Cable Types
9ARD000015-600 21
If the network is already grounded, do not connect the grounding terminal of the tap
or ground of the supply to earth. If more than one supply is on the network, then
connect the drain wire/shield at one supply only, preferably near the physical center
of the network.
Cable Types
The following data consists of the specifications for different cable types:
• Data Pair Specifications.
• Power Pair Specifications.
• General Specifications.
• Topology.
• Physical Configuration.
• Available Bus Electric Current.
Grounding should always be done according to Federal, State and Local
regulations.
The specification lists only 3 types of cables such as Thick cable, Thin cable, and
Flat cable.
