Section 2 Transmission Media and Components Thin Cable
9ARD000015-600 29
Electrical
Table 16
DC Power Specification
Physical
Table 17
Electrical
Table 18
General Specification
Physical
Table 19
Electrical
Table 20
Environmental
Table 21
Table 15. Physical Characteristics of Data Pair Specification for Thin Cables
Physical Characteristics Specification
Conductor pair Size #24 Copper (minimum); 19 strands
minimum (individually tinned)
Insulation diameter 0.077 inches (nominal)
Colors Light Blue
White
Pair Twist/ft 5 (approximately)
Tape shield over pair 1 mil / 1 mil, Al / Mylar
Al side out w/shorting fold
(pull-on applied)
Table 14. Specifications of Thin Cable and their Corresponding Table Numbers (Continued)
Characteristics Table Number
