1-68 ACH550-UH User’s Manual
Parameters
0123 RO 4-6 STATUS 000…111 (0…7 decimal) 1 -
0124
AO 1 0.0…20.0 mA 0.1 mA -
0125 AO 2 0.0…20.0 mA 0.1 mA -
0126
PID 1 OUTPUT -1000.0…1000.0% 0.1% -
0127
PID 2 OUTPUT -100.0…100.0% 0.1% -
0128 PID 1 SETPNT Unit and scale defined by par. 4006/
4106 and 4007/4107
--
0129
PID 2 SETPNT Unit and scale defined by par. 4206 and
4207
--
0130
PID 1 FBK Unit and scale defined by par. 4006/
4106 and 4007/4107
--
0131
PID 2 FBK Unit and scale defined by par. 4206 and
4207
--
0132
PID 1 DEVIATION Unit and scale defined by par. 4006/
4106 and 4007/4107
--
0133
PID 2 DEVIATION Unit and scale defined by par. 4206 and
4207
--
0134
COMM RO WORD 0…65535 1 -
0135
COMM VALUE 1 -32768…+32767 1 -
0136 COMM VALUE 2 -32768…+32767 1 -
0137
PROCESS VAR 1- 1 -
0138
PROCESS VAR 2- 1 -
0139 PROCESS VAR 3- 1 -
0140
RUN TIME 0.00…499.99 kh 0.01 kh -
0141
MWH COUNTER 0…65535 MWh 1 MWh -
0142 REVOLUTION CNTR 0…65535 Mrev 1 Mrev -
0143
DRIVE ON TIME HI 0…65535 days 1 day -
0144
DRIVE ON TIME LO 00:00:00…23:59:58 1 = 2 s -
0145 MOTOR TEMP Par. 3501 = 1…3: -10…200 °C
Par. 3501 = 4: 0…5000 ohm
Par. 3501 = 5…6: 0…1
1-
0150
CB TEMP -20.0…150.0 °C 1.0 °C -
0153
MOT THERM STRESS 0.0…100.0% 0.1% -
0158
PID COMM VALUE 1 -32768 …+32767 1 -
0159
PID COMM VALUE 2 -32768 …+32767 1 -
0174
SAVED KWH 0.0…999.9 kWh 0.1 kWh -
0175
SAVED MWH 0…65535 MWh 1 MWh -
0176
SAVED AMOUNT 1 0.0…999.9 0.1 -
0177
SAVED AMOUNT 2 0…65535 1 -
0178
SAVED CO2 0.0…6553.5 tn 0.1 tn -
Group 03: FB ACTUAL SIGNALS
0301
FB CMD WORD 1- 1 -
0302
FB CMD WORD 2- 1 -
0303 FB STS WORD 1- 1 -
0304
FB STS WORD 2- 1 -
0305
FAULT WORD 1- 1 -
0306
FAULT WORD 2- 1 -
Code Name Range Resolution Default User S
