ACH550-UH User’s Manual 1-69
Parameters
0307 FAULT WORD 3- 1 -
0308
ALARM WORD 1- 1 -
0309 ALARM WORD 2- 1 -
Group 04: FAULT HISTORY
0401
LAST FAULT Fault codes (panel displays as text) 1 0
0402 FAULT TIME 1 Date dd.mm.yy / power-on time in days 1 day 0
0403
FAULT TIME 2 Time hh.mm.ss 2 s 0
0404 SPEED AT FLT -32768…+32767 1 rpm 0
0405
FREQ AT FLT -3276.8…+3276.7 0.1 Hz 0
0406
VOLTAGE AT FLT 0.0…6553.5 0.1 V 0
0407 CURRENT AT FLT 0.0…6553.5 0.1 A 0
0408
TORQUE AT FLT -3276.8…+3276.7 0.1% 0
0409
STATUS AT FLT 0000…FFFF hex 1 0
0410
DI 1-3 AT FLT 000…111 (0…7 decimal) 1 0
0411
DI 4-6 AT FLT 000…111 (0…7 decimal) 1 0
0412
PREVIOUS FAULT 1 As par. 0401 1 0
0413 PREVIOUS FAULT 2 As par. 0401 1 0
Group 10: START/STOP/DIR
1001
EXT1 COMMANDS 0…14 1 1 (DI1) 
1002 EXT2 COMMANDS 0…14 1 1 (DI1) 
1003
DIRECTION 0…3 1 1 (FORWARD) 
Group 11: REFERENCE SELECT
1101 KEYPAD REF SEL 1, 2 1 1 [REF1(Hz/rpm)]
1102
EXT1/EXT2 SEL -6…12 1 0 (EXT1) 
1103
REF1 SELECT 0…17, 20…21 1 1 (AI1) 
1104 REF1 MIN 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
1105
REF1 MAX 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 60.0 Hz (US) /
1800 rpm (US)
1106
REF2 SELECT 0…17, 19…21 1 19 (PID1OUT) 
1107
REF2 MIN 0.0…100.0% (0.0…600.0% for torque) 0.1% 0.0%
1108
REF2 MAX 0.0…100.0% (0.0…600.0% for torque) 0.1% 100.0%
Group 12: CONSTANT SPEEDS
1201
CONST SPEED SEL -14 …19 1 3 (DI3) 
1202
CONST SPEED 1 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 6.0 Hz / 360 rpm (US)
1203
CONST SPEED 2 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 12.0 Hz / 720 rpm (US)
1204
CONST SPEED 3 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 18.0 Hz / 1080 rpm
(US)
1205
CONST SPEED 4 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 24.0 Hz / 1440 rpm
(US)
1206
CONST SPEED 5 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 30.0 Hz / 1800 rpm
(US)
1207
CONST SPEED 6 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 48.0 Hz / 2880 rpm
(US)
1208
CONST SPEED 7 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 60.0 Hz / 3600 rpm
(US)
1209
TIMED MODE SEL 1, 2 1 2 (CS1/2/3/4) 
Code Name Range Resolution Default User S
