1-70 ACH550-UH User’s Manual
Parameters
Group 13: ANALOG INPUTS
1301
MINIMUM AI1 0.0…100.0% 0.1% 20.0%
1302 MAXIMUM AI1 0.0…100.0% 0.1% 100.0%
1303
FILTER AI1 0.0…10.0 s 0.1 s 0.1 s
1304
MINIMUM AI2 0.0…100.0% 0.1% 20.0%
1305 MAXIMUM AI2 0.0…100.0% 0.1% 100.0%
1306
FILTER AI2 0.0…10.0 s 0.1 s 0.1 s
Group 14: RELAY OUTPUTS
1401
RELAY OUTPUT 1 0…47 1 1 (READY)
1402
RELAY OUTPUT 2 0…47 1 2 (RUN)
1403 RELAY OUTPUT 3 0…47 1 3 [FAULT(-1)]
1404
RO 1 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1405
RO 1 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1406
RO 2 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1407
RO 2 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1408
RO 3 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1409 RO 3 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1410
RELAY OUTPUT 4 0…47 1 0 (NOT SEL)
1411
RELAY OUTPUT 5 0…47 1 0 (NOT SEL)
1412 RELAY OUTPUT 6 0…47 1 0 (NOT SEL)
1413
RO 4 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1414
RO 4 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1415 RO 5 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1416
RO 5 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1417
RO 6 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1418 RO 6 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
Group 15: ANALOG OUTPUTS
1501
AO1 CONTENT SEL 99…178 1 103 (OUTPUT FREQ)
1502 AO1 CONTENT MIN Depends on selection - 0.0 Hz
1503
AO1 CONTENT MAX Depends on selection - 60.0 Hz
1504
MINIMUM AO1 0.0…20.0mA 0.1mA 4.0mA
1505
MAXIMUM AO1 0.0…20.0 mA 0.1 mA 20.0 mA
1506
FILTER AO1 0.0…10.0s 0.1s 0.1s
1507
AO2 CONTENT SEL 99…178 1 104 (CURRENT)
1508
AO2 CONTENT MIN Depends on selection - 0.0 A
1509
AO2 CONTENT MAX Depends on selection - 1.0 · I
2n
A
1510
MINIMUM AO2 0.0…20.0mA 0.1mA 4.0mA
1511
MAXIMUM AO2 0.0…20.0 mA 0.1 mA 20.0 mA
1512
FILTER AO2 0.0…10.0s 0.1s 0.1s
Group 16: SYSTEM CONTROLS
1601
RUN ENABLE -6…7 1 0 (NOT SEL) 
1602
PARAMETER LOCK 0…2 1 1 (OPEN)
1603
PASS CODE 0…65535 1 0
1604
FAULT RESET sEL -6…8 1 0 (KEYPAD)
1605
USER PAR SET CHG -6…6 1 0 (NOT SEL)
Code Name Range Resolution Default User S
