Parameters
1606 LOCAL LOCK -6…8 1 0 (NOT SEL)
1607
PARAM SAVE 0, 1 1 0 (DONE)
1608 START ENABLE 1 -6…7 1 4 (DI4) 
1609
START ENABLE 2 -6…7 1 0 (NOT SEL) 
1610
DISPLAY ALARMS 0, 1 1 1 (YES)
1611 PARAMETER VIEW 0, 1 1 0 (DEFAULT)
1612
FAN CONTROL 0, 1 1 0 (AUTO)
1613 FAULT RESET 0, 1 1 0 (DEFAULT)
Group 17: OVERRIDE
1701
OVERRIDE SEL -6…6 1 0 (NOT SEL) 
1702 OVERRIDE FREQ -500…500 Hz 0.1 0.0 Hz 
1703
OVERRIDE SPEED -30.000…30.000 rpm 1 0 rpm 
1704
OVERR PASS CODE 0…65535 1 0 
1705
OVERRIDE 0…1 1 0 (OFF) 
1706
OVERRIDE DIR -6...7 1 0 (FORWARD) 
1707
OVERRIDE REF 1, 2 1 1 (CONSTANT) 
Group 20: LIMITS
2001
MINIMUM SPEED -30000…30000 rpm 1 rpm 0 rpm 
2002
MAXIMUM SPEED 0…30000 rpm 1 rpm 1800 rpm (US) 
2003 MAX CURRENT 0… 1.3 · I
2n
0.1 A 1.3 · I
2n

2006
UNDERVOLT CTRL 0…2 1 1 [ENABLE(TIME)]
2007
MINIMUM FREQ -500.0…500.0 Hz 0.1 Hz 0.0 Hz 
2008 MAXIMUM FREQ 0.0…500.0 Hz 0.1 Hz 60.0 Hz (US) 
2013
MIN TORQUE SEL -6…7 1 0 (MIN TORQUE 1)
2014
MAX TORQUE SEL -6…7 1 0 (MAX TORQUE 1)
2015 MIN TORQUE 1 -600.0…0.0% 0.1% -300.0%
2016
MIN TORQUE 2 -600.0…0.0% 0.1% -300.0%
2017
MAX TORQUE 1 0.0…600.0% 0.1% 300.0%
2018 MAX TORQUE 2 0.0…600.0% 0.1% 300.0%
Group 21: START/STOP
2101
START FUNCTION Vector control modes: 1, 2, 8
Scalar control mode: 1…5, 8
13 (SCALAR FLYST) 
2102
STOP FUNCTION 1, 2 1 1 (COAST)
2103
DC MAGN TIME 0.00…10.00 s 0.01 s 0.30 s
2104
DC HOLD CTL 0…2 1 0 (NOT SEL) 
2105
DC HOLD SPEED 0…360 rpm 1 rpm 5 rpm
2106
DC CURR REF 0…100% 1% 30%
2107
DC BRAKE TIME 0.0…250.0 s 0.1 s 0.0 s
2108
START INHIBIT 0, 1 1 0 (OFF)
2109
EMERG STOP SEL -6…6 1 0 (NOT SEL)
2110
TORQ BOOST CURR 15…300% 1% 100%
2113 START DELAY 0.00…60.00 s 0.01 s 0.00 s
Code Name Range Resolution Default User S
