1-72 ACH550-UH User’s Manual
Parameters
Group 22: ACCEL/DECEL
2201
ACC/DEC 1/2 SEL -6…7 1 0 (NOT SEL)
2202 ACCELER TIME 1 0.0…1800.0 s 0.1 s 30.0 s
2203
DECELER TIME 1 0.0…1800.0 s 0.1 s 30.0 s
2204
RAMP SHAPE 1 0.0…1000.0 s 0.1 s 0.0 (LINEAR)
2205 ACCELER TIME 2 0.0…1800.0 s 0.1 s 60.0 s
2206
DECELER TIME 2 0.0…1800.0 s 0.1 s 60.0 s
2207 RAMP SHAPE 2 0.0…1000.0 s 0.1 s 0.0 (LINEAR)
2208
EMERG DEC TIME 0.0…1800.0 s 0.1 s 1.0 s
2209
RAMP INPUT 0 -6…7 1 0 (NOT SEL)
Group 23: SPEED CONTROL
2301
PROP GAIN 0.00…200.00 0.01 3.00
2302
INTEGRATION TIME 0.00…600.00 s 0.01 s 0.50 s
2303
DERIVATION TIME 0…10000 ms 1 ms 0 ms
2304
ACC COMPENSATION 0.00…600.00 s 0.01 s 0.00 s
2305
AUTOTUNE RUN 0, 1 1 0 (OFF)
Group 25: CRITICAL SPEEDS
2501
CRIT SPEED SEL 0, 1 1 0 (OFF)
2502
CRIT SPEED 1 LO 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
2503 CRIT SPEED 1 HI 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
2504
CRIT SPEED 2 LO 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
2505
CRIT SPEED 2 HI 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
2506 CRIT SPEED 3 LO 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
2507
CRIT SPEED 3 HI 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm 0.0 Hz / 0 rpm
Group 26: MOTOR CONTROL
2601 FLUX OPT ENABLE 0, 1 1 1 (ON)
2602
FLUX BRAKING 0, 1 1 0 (OFF)
2603
IR COMP VOLT 0.0…100.0 V 0.1 V 0.0 V
2604 IR COMP FREQ 0…100% 1% 80%
2605
U/F RATIO 1, 2 1 2 (SQUARED)
2606
SWITCHING FREQ 1, 2, 4, 8, 12 kHz - 4 kHz
2607
SWITCH FREQ CTRL 0, 1 1 1 (ON)
2608
SLIP COMP RATIO 0…200% 1% 0%
2609
NOISE SMOOTHING 0, 1 1 0 (DISABLE)
2619
DC STABILIZER 0, 1 1 0 (DISABLE)
2625
OVERMODULATION 0, 1 1 0 (DISABLE)
Group 29: MAINTENANCE TRIG
2901
COOLING FAN TRIG 0.0…6553.5 kh, 0.0 disables 0.1 kh 0.0 kh
2902
COOLING FAN ACT 0.0…6553.5 kh 0.1 kh 0.0 kh
2903
REVOLUTION TRIG 0…65535 Mrev, 0 disables 1 Mrev 0 Mrev
2904
REVOLUTION ACT 0…65535 Mrev 1 Mrev 0 Mrev
2905
RUN TIME TRIG 0.0…6553.5 kh, 0.0 disables 0.1 kh 0.0 kh
2906
RUN TIME ACT 0.0…6553.5 kh 0.1 kh 0.0 kh
2907
USER MWh TRIG 0.0…6553.5 MWh, 0.0 disables 0.1 MWh 0.0 MWh
2908
USER MWh ACT 0.0…6553.5 MWh 0.1 MWh 0.0 MWh
Code Name Range Resolution Default User S
