ACH550-UH User’s Manual 1-73
Parameters
Group 30: FAULT FUNCTIONS
3001
AI<MIN FUNCTION 0…3 1 0 (NOT SEL)
3002
PANEL COMM ERR 1…3 1 1 (FAULT)
3003 EXTERNAL FAULT 1 -6…6 1 0 (NOT SEL)
3004
EXTERNAL FAULT 2 -6…6 1 0 (NOT SEL)
3005
MOT THERM PROT 0…2 1 1 (FAULT)
3006 MOT THERM TIME 256…9999 s 1 s 1050 s
3007
MOT LOAD CURVE 50…150% 1% 100%
3008
ZERO SPEED LOAD 25…150% 1% 70%
3009 BREAK POINT FREQ 1…250Hz 1Hz 35Hz
3010
STALL FUNCTION 0…2 1 0 (NOT SEL)
3011
STALL FREQUENCY 0.5…50.0 Hz 0.1 Hz 20.0 Hz
3012
STALL TIME 10…400 s 1 s 20 s
3017
EARTH FAULT 0, 1 1 1 (ENABLE) 
3018
COMM FAULT FUNC 0…3 1 0 (NOT SEL)
3019
COMM FAULT TIME 0.0…600.0 s 0.1 s 10.0 s
3021
AI1 FAULT LIMIT 0.0…100.0% 0.1% 0.0%
3022 AI2 FAULT LIMIT 0.0…100.0% 0.1% 0.0%
3023
WIRING FAULT 0, 1 1 1 (ENABLE) 
3024
CB TEMP FAULT 0, 1 1 1 (ENABLE)
3028 EARTH FAULT LVL 1…3 1 1 (LOW)
Group 31: AUTOMATIC RESET
3101
NUMBER OF TRIALS 0…5 1 5
3102 TRIAL TIME 1.0…600.0 s 0.1 s 30.0 s
3103
DELAY TIME 0.0…120.0 s 0.1 s 6.0 s
3104
AR OVERCURRENT 0, 1 1 0 (DISABLE)
3105 AR OVERVOLTAGE 0, 1 1 1 (ENABLE)
3106
AR UNDERVOLTAGE 0, 1 1 1 (ENABLE)
3107
AR AI<MIN 0, 1 1 1 (ENABLE)
3108 AR EXTERNAL FLT 0, 1 1 1 (ENABLE)
Group 32: SUPERVISION
3201
SUPERV 1 PARAM 100…178 1 103 (OUTPUT FREQ)
3202 SUPERV 1 LIM LO Depends on selection - 60.0 Hz
3203
SUPERV 1 LIM HI Depends on selection - 60.0 Hz
3204
SUPERV 2 PARAM 100…178 1 104 (CURRENT)
3205
SUPERV 2 LIM LO Depends on selection - 1.0 · I
2n
A
3206
SUPERV 2 LIM HI Depends on selection - 1.0 · I
2n
A
3207
SUPERV 3 PARAM 100…178 1 105 (TORQUE)
3208
SUPERV 3 LIM LO Depends on selection - 100.0%
3209
SUPERV 3 LIM HI Depends on selection - 100.0%
Group 33: INFORMATION
3301
FIRMWARE 0000…FFFF hex 1 -
3302
LOADING PACKAGE 0000…FFFF hex 1 -
3303
TEST DATE yy.ww 0.01 -
3304
DRIVE RATING 0000…FFFF hex 1 -
3305
PARAMETER TABLE 0000…FFFF hex 1 -
Code Name Range Resolution Default User S
