1-78 ACH550-UH User’s Manual
Parameters
Group 53: EFB PROTOCOL
5301
EFB PROTOCOL ID 0000…FFFF hex 1 0000 hex
5302 EFB STATION ID 0…65535 1 1
5303
EFB BAUD RATE 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6,
76.8 kb/s
- 9.6 kb/s
5304
EFB PARITY 0…3 1 0 (8 NONE 1)
5305 EFB CTRL PROFILE 0…2 1 0 (ABB DRV LIM)
5306
EFB OK MESSAGES 0…65535 1 0
5307
EFB CRC ERRORS 0…65535 1 0
5308 EFB UART ERRORS 0…65535 1 0
5309
EFB STATUS 0…7 1 0 (IDLE)
5310
EFB PAR 10 0…65535 1 0
5311 EFB PAR 11 0…65535 1 0
5312
EFB PAR 12 0…65535 1 0
5313
EFB PAR 13 0…65535 1 0
5314 EFB PAR 14 0…65535 1 0
5315
EFB PAR 15 0…65535 1 0
5316
EFB PAR 16 0…65535 1 0
5317 EFB PAR 17 0…65535 1 0
5318
EFB PAR 18 0…65535 1 0
5319
EFB PAR 19 0000…FFFF hex 1 0000 hex
5320 EFB PAR 20 0000…FFFF hex 1 0000 hex
Group 64: LOAD ANALYZER
6401
PVL SIGNAL 100…178 1 103 (OUTPUT FREQ)
6402 PVL FILTER TIME 0.0…120.0 s 0.1 s 0.1 s
6403
LOGGERS RESET -6…7 1 0 (NOT SEL)
6404
AL2 SIGNAL 101…178 1 103 (OUTPUT FREQ)
6405 AL2 SIGNAL BASE Depends on selection - 60.0 Hz
6406
PEAK VALUE ---
6407
PEAK TIME 1 Date dd.mm.yy / power-on time in days 1 d -
6408
PEAK TIME 2 Time hh.mm.ss 2 s -
6409
CURRENT AT PEAK 0.0…6553.5 A 0.1 A -
6410
UDC AT PEAK 0…65535 V 1 V -
6411
FREQ AT PEAK 0.0…6553.5 Hz 0.1 Hz -
6412
TIME OF RESET 1 Date dd.mm.yy / power-on time in days 1 d -
6413
TIME OF RESET 2 Time hh.mm.ss 2 s -
6414
AL1RANGE0TO10 0.0…100.0% 0.1% -
6415
AL1RANGE10TO20 0.0…100.0% 0.1% -
6416
AL1RANGE20TO30 0.0…100.0% 0.1% -
6417
AL1RANGE30TO40 0.0…100.0% 0.1% -
6418
AL1RANGE40TO50 0.0…100.0% 0.1% -
6419 AL1RANGE50TO60 0.0…100.0% 0.1% -
6420
AL1RANGE60TO70 0.0…100.0% 0.1% -
6421
AL1RANGE70TO80 0.0…100.0% 0.1% -
6422
AL1RANGE80TO90 0.0…100.0% 0.1% -
Code Name Range Resolution Default User S
