ABB ACH580-34 - Step-by-Step Installation Diagrams

Step-by-step drawings for an installation example of standard drive configuration in Rittal VX25 800 mm wide cabinet 9
Step-by-step drawings for an installation example of standard drive configuration in Rittal VX25 800 mm wide cabinet
INPUT
OUTPUT
U1
V1
W1
3 ~
M
(PE) PE (PE)
3
4
5
6
7
9
L1
L2 L3
L1
L2
L3
1
2a 2b
PE
L1/
U1 V1
L2/ L3/
W1
UDC- UDC+
T1/
U2
T2/
V2
T3/
W2
PE
8
10
11
ACH580-34
1
2
3
Drive type
ACH580-34-
Air flow Losses Type DIN 43653
m
3
/h W
U
N
= 400 V IEC
246A-4 2100 5280 170M5408
293A-4 2100 6400 170M5410
365A-4 2100 8000 170M6410
442A-4 2100 10000 170M6411
505A-4 2100 10000 170M6412
585A-4 2100 12600 170M6414
650A-4 2100 14200 170M6414
U
N
= 480 V IEC
246A-4 2100 5220 170M4410
293A-4 2100 5220 170M5408
365A-4 2100 7830 170M5410
442A-4 2100 9135 170M6410
505A-4 2100 9135 170M6411
585A-4 2100 9135 170M6411
650A-4 2100 10440 170M6412
U
N
= 480 V UL
240A-4 2100 5280 170M4410
302A-4 2100 6525 170M5408
361A-4 2100 7830 170M5410
414A-4 2100 9135 170M6410
477A-4 2100 10440 170M6411
WARNING! The UDC+ and UDC- terminals of the drive
module must not be used for any other than optional external
brake chopper connection.
