ACS/ACC/ACP 601 Hardware Manual 1-1
Chapter 1 – Introduction
*HQHUDO
The ACS 600 product family of three phase frequency converters and
converter modules for speed control of squirrel cage electric motors
includes
• the ACS 600 (for most applications)
• the ACP 600 (for positioning, synchronising and other high-
precision control applications)
• the ACC 600 (for crane drive applications)
• the ACS 600 MultiDrive (for multidrive applications)
The application programs are introduced in
Appendix – A .
Study this manual carefully before installing, commissioning, operating
or servicing the frequency converter. We expect that you have a basic
knowledge of physical and electrical fundamentals, electrical wiring
practices, electrical components and electrical schematic symbols.
For start-up, refer to
Start-up Guide (ACS 600 Standard Application
Program) or
Firmware Manual (ACS 600 Crane Drive and Motion
Control Application Programs).
For optional equipments, refer to their manuals.
For programming the unit, refer to the appropriate
Firmware Manual .
Delivery Check
Check that there are no signs of damage. Before attempting installation
and operation, check the information on the frequency converter
nameplate to verify that the unit is of the correct model.
Each ACx 600 is fitted with a nameplate for identification purposes.
The nameplate data includes a type code and a serial number, which
allow individual recognition of each unit. The type code contains
information on the properties and configuration of the unit. The first
digit of the serial number refers to the manufacturing plant. The next
four digits refer to the unit’s manufacturing year and week, respectively.
The remaining digits complete the serial number so that there are no
two units with the same serial number.
