3 Remove & Modify the UL Type 4X Drive Cover
3.1.1 Loosen the four capsulated screws and remove cover.
3.1.2 Remove CAT5 cable from the drives cover strain relief tabs
and RJ-45 connector.
3.1.3 Remove CAT 5 cable from the drives RJ-45 connector.
Author: Jeff Fell – Application Eng., Greg Semrow – Product
Marketing Date: 8, 2014
External
http://www.abb.us/drives.
Industry – Industrial
Document #: LVD-EOTN72U-EN
Revision: A
Product Categories: ACS355, MPOW, MREL, MTAC
